Description
The Lilliput FA1014-NP/C 10.1" HDMI Monitor sits in our Monitors range.
Key specifications: brightness 350 cd/m²; weight 560 g; dimensions 250.0 x 170.0 x 32.3 mm; screen size (Diagonal) 10.1"; native resolution 1280 x 800.
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks. In the box: Lilliput FA1014-NP/C 10.1" HDMI Monitor, remote control, HDMI Cable, VGA Cable, composite A/V to 1/8" cable and control I/O cable and 2 more items.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Display | |
|---|---|
| Screen Size (Diagonal) | 10.1" |
| Native Resolution | 1280 x 800 |
| Supported Display Resolutions | Maximum: 1920 x 1080 |
| Panel Type | Unspecified LCD |
| Brightness | 350 cd/m² |
| Viewing Angle (H x V) | 170 x 170° |
| Screen Area | 8.5 x 5.3" / 216.96 x 135.6 mm |
| Aspect Ratio | 16:10 |
| Contrast Ratio | 800:1 |
| Response Time | 25 ms |
| Dot Pitch | 0.0565 x 0.1695 mm |
| Backlighting Technology | Edge LED |
| Connectivity | |
| Primary Connectivity Location | Display |
| Input Ports | 1 x HDMI - Audio, Video 1 x DVI - Video 1 x 15-Pin VGA - Video 1 x 1/8" (3.5 mm) Mini - Audio, Video |
| Digital Media Slot | None |
| General | |
| TV Tuner | No |
| Audio | |
| Built-In Speakers | Yes, 1 W |
| Speaker Configuration | 1-Channel |
| Convenience | |
| Supported Languages | English Traditional Chinese |
| Electrical | |
| Power Consumption | Operational: 10.0 W |
| DC Input Power | 7 to 24 VDC at 800 mA 12 VDC at 1.5 A |
| Environmental | |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 60°C |
| Operating Humidity | 90% |
| Physical | |
| Dimensions | 250.0 x 170.0 x 32.3 mm |
| Weight | 560 g |
Product details
| Screen Resolution | 1280 x 800 |
|---|---|
| Screen Size | 10.1" |
In the box
- Lilliput FA1014-NP/C 10.1" HDMI Monitor
- Remote Control
- HDMI Cable
- VGA Cable
- Composite A/V to 1/8" Cable
- Control I/O Cable
- 12 VDC Adapter
- Car Power Adapter
