Description
The FeelWorld P6X is a compact 5.5 inch on-camera monitor for shooters who want a small display with touch control and 4K HDMI monitoring. It suits DSLR, mirrorless and production setups where the camera screen is hard to see, and it gives a clearer view of framing, focus and exposure on set.
It has a 1920 x 1080 IPS display with 1000 nits brightness, a 16:9 aspect ratio and a 160 degree viewing angle. HDMI 2.0 input and output support 4K signals, and Hybrid Log Gamma HDR is available. Power options include 12 VDC input, 8 VDC output and USB-C 5 V input. It also offers a 3.5 mm headphone output, a stereo speaker and support for up to 32 custom 3D LUTs.
In use, it mounts to a rig or camera with 1/4-20 female threads on the bottom, top and right side. It pairs with cameras, transmitters and other HDMI video sources that need a field monitor. The box includes the monitor, HDMI cable, micro-HDMI cable, USB-C to USB-A adapter, mini cold shoe mount and Allen key.
Specifications
| Key Specs | |
|---|---|
| Display Size | 5.5" / 14.0 cm |
| Native Resolution | 1920 x 1080 |
| Touchscreen | Yes |
| HDR Support | Yes, Hybrid Log Gamma |
| Video I/O | 1x HDMI 2.0 Input 1x HDMI 2.0 Output |
| Media/Memory Card Slot | No |
| Video Format | HDMI DCI 4K: 60/50/30/29.97/25/24/23.98 UHD 4K: 60/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 576p 576i 480p 480i |
| Power Consumption | 10 W |
| Mounting | 1x 1/4"-20 Female (Bottom) 1x 1/4"-20 Female (Top) 1x 1/4"-20 Female (Right) |
| Display | |
| Panel Type | IPS-Type LCD |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 160° (80/80) Vertical: 160° (80/80) |
| Maximum Brightness | 1000 nits / cd/m 2 |
| Contrast Ratio | 1000:1 |
| Pixels Per Inch (ppi) | 400 ppi |
| Image Controls | Anamorphic De-Squeeze, Cheque Field, False Colour, Histogram, Image Flip, Image Freeze, Overscan, Pixel-to-Pixel Zoom, Screen Markers, Vectorscope, Waveform |
| Inputs / Outputs | |
| Embedded Audio | HDMI |
| Audio I/O | 1x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | Stereo |
| Power I/O | 1x Barrel (12 VDC) Input 1x Barrel (8 VDC) Output 1x USB-C (5 VDC) Input |
| Other I/O | 1x USB-C (Firmware/LUT Upload) Input [Shared with Power] |
| Wi-Fi | No |
| Bluetooth | No |
| Mobile App Compatible | No |
| Power | |
| Input Power | 7 to 24 VDC |
| General | |
| Operating Conditions | -4 to 122°F / -20 to 50°C |
| Storage Conditions | -22 to 140°F / -30 to 60°C |
| Material of Construction | Aluminium |
| Dimensions | 5.5 x 3.3 x 0.9" / 138.5 x 84.5 x 22 mm |
| Weight | 0.5 lb / 249 g |
Product details
| Screen Size | 5.5" |
|---|---|
| Connection | HDMI |
| Screen Resolution | 1920 x 1080 |
In the box
- FeelWorld P6X 5.5" 4K HDMI Touchscreen Monitor
- HDMI Cable
- Micro-HDMI Cable
- USB-C to USB-A Adapter
- Mini Cold Shoe Mount
- Allen Key
