Description
The Portkeys BM5 IV 5.5" HDMI/3G-SDI Camera Monitor sits in our Monitors range.
Highlights include built-in CINENORM OS, brand new user interface, split-screen monitoring and professional monitoring.
Key specifications: connection 3G-SDI; battery support NP-F970/F960/F750/F550; brightness 2000nits; weight 350g; dimensions 145.4 x 91.4 x 39.6mm.
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Screen size | 5.5" |
|---|---|
| Material | Aluminium alloy |
| Brightness | 2000nits |
| Colour depth | 10bit |
| Audio output | 3.5mm headphone jack |
| Camera control interface | Remote |
| Signal output | 3G SDI, HDMI |
| Signal input | 3G SDI, HDMI |
| Operating system | CINENORM OS |
| Input voltage | 7-24V |
| Resolution | 1920 x 1080 |
| Viewing angle | 178°H/178°V |
| Battery support | NP-F970/F960/F750/F550 |
| Power input | 4-pin aviation connector |
| Maximum power | 16W |
| Contrast ratio | 1000:1 |
| Fan | Yes |
| Dimensions | 145.4 x 91.4 x 39.6mm |
| Weight | 350g |
Product details
| Connection | 3G-SDI |
|---|---|
| Screen Resolution | 1920 x 1080 |
In the box
- Portkeys BM5 IV 5.5" HDMI/3G-SDI Camera Monitor
