Description
The FeelWorld F6 Plus X 5.5" 4K HDMI Monitor sits in our Monitors range.
Highlights include touchscreen 1920 x 1080 display, 1200cd/m², up to DCI 4K HDMI input; HDMI output, LUT support via SD card slot and DC, USB, L-Series/LP-E6 Power support.
Key specifications: mounting 3 x 1/4"-20 Female; battery type 1 x LP-E6; weight 8.9 oz / 253 g; dimensions 5.8 x 3.7 x 0.8" / 148 x 93 x 20 mm; screen size 5.5".
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks. In the box: FeelWorld F6 plus X 5.5" 4K HDMI Monitor, 1x HDMI to Mini HDMI Cable, 1x Tilt Arm, 1x Sunshade and 1x Manual.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Display | |
|---|---|
| Panel Type | IPS-Type LCD |
| Display Size | 5.5" / 14.0 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 160° Vertical: 160° |
| Touchscreen | Yes |
| Maximum Brightness | 1200 nits / cd/m 2 |
| Contrast Ratio | 1000:1 |
| Dot Pitch | 69.00 x 69.00 µm |
| Bit Depth / Colour Support | 8-Bit (16.7 Million Colours) |
| HDR Compatibility | None |
| Pixels Per Inch (ppi) | 400 ppi |
| Image Controls | Focus Assist, Histogram, R/G/B/Chroma Only, Waveform |
| Inputs / Outputs | |
| Video I/O | 1 x HDMI Input 1 x HDMI Output |
| Embedded Audio | HDMI |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | None |
| Power I/O | 1 x Barrel 5.5 mm (12 VDC) Input 1 x USB-C (5 VDC) Input 1 x Barrel 5.5 mm (8 VDC) Output |
| Media/Memory Card Slot | Single Slot: SD/SDHC |
| Wi-Fi | None |
| Bluetooth | None |
| Mobile App Compatible | No *As of June, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Format Support | |
| Video Format | HDMI (8-Bit) DCI 4K: 24 UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50/30/29.97/25/24/23.98 720p: 60/59.94/50/30/29.97/25/24/23.98 576p 576i 480p 480i |
| Power | |
| DC Input Power | 7 to 24 VDC |
| Battery Type | 1 x LP-E6 |
| Power Consumption | 9 W (Maximum) |
| Mounting | |
| Mounting | 3 x 1/4"-20 Female |
| Environmental | |
| Environmental Protection | None |
| General | |
| Dimensions | 5.8 x 3.7 x 0.8" / 148 x 93 x 20 mm |
| Weight | 8.9 oz / 253 g |
Product details
| Screen Size | 5.5" |
|---|---|
| Screen Resolution | 1920 x 1080 |
| Display Size | 5.5 inches |
In the box
- FeelWorld F6 Plus X 5.5" 4K HDMI Monitor
- 1x HDMI to Mini HDMI Cable
- 1x Tilt Arm
- 1x Sunshade
- 1x Manual
