Description
The Shure BLX24R Vocal Wireless System with SM58 Mic (M17: 662 - 686 MHz) sits in our Wireless Systems range.
Highlights include H8 frequency band, BLX4R rackmountable wireless receiver, BLX2 transmitter with SM58 mic, one-touch QuickScan frequency selection and diversity antennas.
Key specifications: polar pattern Cardioid; frequency response 50 Hz to 15 kHz; weight 218 g; dimensions (Ø x L) 53 x 224 mm; gain adjustment range 10 dB.
The transmitter clips to the talent and the receiver sits on the camera or phone, so no cable is in shot. In the box: BLX2 Handheld Transmitter with SM58 Microphone (M17: 662 - 686 MHz), 2 x AA Batteries, microphone clip, BLX4R Single-Channel Wireless Rackmount Receiver (M17: 662 - 686 MHz) and rackmount hardware kit. Manufacturer model number BLX24R/SM58-M17.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Transmitter | |
|---|---|
| Audio Input Level | 0 dB Gain: -20 dBV Maximum -10 dB Gain: -10 dBV Maximum |
| Gain Adjustment Range | 10 dB |
| RF Output | 10 mW, Typical (Varies by Region) |
| Power Requirement | 2x LR6 AA Batteries, 1.5 V Alkaline |
| Housing | Moulded ABS |
| Dimensions (Ø x L) | 53 x 224 mm |
| Weight | 218 g |
| Microphone | |
| Frequency Response | 50 Hz to 15 kHz |
| Polar Pattern | Cardioid |
| Output Level | -54.5 dBV/PA (1.85 mV) |
| BLX4R Single-Channel Wireless Rackmount Receiver (M17: 662 - 686 MHz) | |
| Output | 1x XLR Output 1x 1/4" (6.35 mm) Output |
| Output Impedance | XLR: 200 ohms 1/4": 50 ohms |
| Audio Output Level | XLR Connector: -20.5 dBV into 100 kOhms Load (Reference +/-33 kHz with 1 kHz Tone) 1/4": -13 dBV into 100 kOhms Load (Reference +/-33 kHz with 1 kHz Tone) |
| RF Sensitivity | -105 dBm for 12 dB SINAD, Typical |
| Image Rejection | >50 dB, Typical |
| Housing | Moulded ABS, Steel |
| Power Requirement | 12 to 15 VDC @ 260 mA, Supplied by External Power Supply (Tip Positive) |
| Dimensions (H x W x D) | 50 x 198 x 163 mm |
| Weight | 998 g |
Product details
| Element Type | Dynamic |
|---|
In the box
- BLX2 Handheld Transmitter with SM58 Microphone (M17: 662 - 686 MHz)
- 2 x AA Batteries
- Microphone Clip
- BLX4R Single-Channel Wireless Rackmount Receiver (M17: 662 - 686 MHz)
- Rackmount Hardware Kit
