Description
The Neumann TLM 103 Large-Diaphragm Condenser Microphone (Nickel) sits in our Large Diaphragm range.
Highlights include large diaphragm capsule cardioid microphone, pressure gradient transducer, transformerless circuitry, low noise and straightforward handling.
Key specifications: polar pattern Cardioid; frequency range 20 Hz to 20 kHz; length 132 mm; weight 450 g; operating principle Pressure Gradient.
A condenser microphone captures detail and high frequencies, which suits vocals, voice-over and acoustic instruments in a quiet room. In the box: TLM 103 Microphone, SG 2 Swivel Mount and Wooden box.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Analogue Performance | |
|---|---|
| Operating Principle | Pressure Gradient |
| Transducer | Condenser |
| Polar Pattern | Cardioid |
| Frequency Range | 20 Hz to 20 kHz |
| Signal to Noise Ratio | 76 dB CCIR 87 dB A-Weighted |
| Equivalent Noise Level | 7 dB A-Weighted |
| Maximum SPL | 138 dB SPL |
| THD | 0.5% |
| Impedance | 50 Ohms |
| Load Impedance | 1000 Ohms |
| Sensitivity | 23 mV/Pa at 1 kHz into 1 kOhms |
| General | |
| Output Connectors | 1 x 3-Pin XLR |
| Operating Current Consumption | 3 µA |
| Operating Voltage | 48 V ± 4 V |
| Length | 132 mm |
| Diameter | 60 mm |
| Weight | 450 g |
In the box
- TLM 103 Microphone
- SG 2 Swivel Mount
- Wooden Box
