Description
The IK Multimedia AXE I/O One Desktop Audio Interface sits in our Audio Input & Output range.
Highlights include 1-In / 3-Out compact Audio interface, adjustable input impedance with Z-TONE, PURE Class-A mic preamp with JFET stage, active or passive pickup selection and amp out with ground loop interrupter.
Key specifications: frequency response 3 Hz to 32 kHz; weight 0.8 lb / 0.4 kg; dimensions 5.5 x 5 x 2.75" / 14 x 12.7 x 6.99 cm; channels of I/O 1 Input / 3 Outputs at 192 kHz; form factor Desktop.
An audio interface powers XLR microphones and converts their signal for recording on a computer. In the box: IK Multimedia AXE I/O One Desktop Audio Interface and USB Connection Cable. Manufacturer model number IP-INT-AXEIOONE-IN.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Form Factor | Desktop |
|---|---|
| Display | None |
| Channels of I/O | 1 Input / 3 Outputs at 192 kHz |
| Built-In DSP | None |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Preamps | 1 Preamp |
| Built-In Microphone | None |
| Input Level Adjustment | 1 x Knob |
| Expansion Slots | None |
| Signal Processing | |
| Pad | None |
| High-Pass Filter | None |
| Solo/Mute | None |
| Connectivity | |
| Analogue Audio I/O | 1 x Combo XLR-1/4" 3-Pin Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel) 2 x 1/4" TS Line Output 1 x 1/4" TS Re-Amp Output (Front Panel) 1 x 1/4" TRS Headphone Output |
| Phantom Power | 48 V, Selectable On/Off |
| Digital Audio I/O | None |
| Host Connection / USB | 1 x USB-C (on Interface) |
| Host Connection Protocol | USB 2.0 |
| USB (Non-Host) | 1 x USB-C (USB 2.0, Power Input) |
| Sync I/O | None |
| Network I/O | None |
| MIDI I/O | 1 x DIN 5-Pin Input 1 x DIN 5-Pin Output |
| Other I/O | 1 x 1/4" TRS Footswitch/Control Input 1 x 1/4" TRS Footswitch/Control Output |
| Wireless Connectivity | None |
| Performance | |
| Frequency Response | 3 Hz to 32 kHz |
| Dynamic Range | 117 dB |
| Digital Audio | |
| Sample Rates | 192 kHz |
| Sample Rate Conversion | None |
| Bit Depths | 24-Bit |
| Sync Sources | MIDI Time Code (MTC) |
| Audio Storage & Playback | |
| Memory Card Slot | None |
| Compatibility | |
| OS Compatibility | Windows macOS *As of February, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Included Software | Ableton Live Lite |
| Compatible Software (Not Included) | Any Core Audio (Mac) Compliant Software |
| Included Plug-Ins | Special Processing: AmpliTube 5 SOE TONEX SOE |
| Mobile App Compatible | No *As of February, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Required Hardware | USB Cable, USB-C Port |
| Power | |
| Power Requirements | USB Bus Power |
| AC/DC Power Adapter | 5 VDC |
| Physical | |
| Anti-Theft Features | Kensington Security Slot |
| Dimensions | 5.5 x 5 x 2.75" / 14 x 12.7 x 6.99 cm |
| Weight | 0.8 lb / 0.4 kg |
In the box
- IK Multimedia AXE I/O One Desktop Audio Interface
- USB Connection Cable
