Description
The X-keys USB Three-Switch Interface sits in our Footswitch & Remotes range.
Highlights include 1 x USB Connector, 1 x 3.5mm TRRS Port, compact form factor, accepts 3.5mm mono, stereo, or TRRS plug and Windows / Android / Mac compatible.
Key specifications: weight 23 g; dimensions 71 x 19 x 13 mm; wiring distance Up to 300 m from switch to port; certification FCC class B, COE, RoHS, WEEE compliant.
Manufacturer model number XK-1283-UJS3-R.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Operating system | Any OS via USB HID | Programming: Windows XP through 8, Mac OS X 10.4 through 10.10 |
|---|---|
| Programming Software | Windows: MacroWorks 3.1 Android: X-keys Android Mac OS X: ControllerMate |
| Software Development Kits | Windows (C++, C#, VB.NETT) Linux (C++) Android (Java) Raw HID (any language/OS) USB Codes Supported: HID keyboard, HID mouse, HID game controller, HID multimedia |
| Ports | 1x 3.5mm TRRS (Tip-Ring-Ring-Sleeve) accepts 3.5mm mono, stereo, or TRRS plug; May be split to accept up to three switches |
| Connector | USB 2.0 standard "A" plug USB 1.1, compatible through 3.0 |
| Wiring Distance | Up to 300 m from switch to port |
| Memory | Memory Capacity: Approximately 1000 keystrokes or commands Memory Type: EEPROM, non volatile memory (X-keys retains memory for over 200 years) |
| Power | Power Source: USB port, nominal voltage = 5 VDC Power Consumption: 21 mA @ 5 VDC |
| Environmental | Temperature Range: -20 to 60°C Environmental Rating: IP 40, typical indoor office environment |
| Certification | FCC class B, COE, RoHS, WEEE compliant |
| Dimensions | 71 x 19 x 13 mm |
| Weight | 23 g |
