Description
The SmallRig 4985 X-Touch Smart Triple-Proof V-Mount Battery X221 sits in our V-Mount range.
Highlights include 1.5m (4.9ft) drop-proof, IP54 waterproof / dustproof, multi-port Power hub, smart app control, 140W PD 3.1 fast charging and 2.0" large touchscree.
Key specifications: battery type Lithium-ion Battery; battery Lithium-Ion; material(s) Flame-retardant PC, Silicone, Aluminum Alloy; product dimensions 145.2 x 92.0 x 91.5mm / 5.7 x 3.6 x 3.6in; product weight 1564 ± 10g / 55 ± 0.4oz.
A V-mount battery powers a camera and accessories from one pack through D-Tap and USB outputs. In the box: SmallRig 4985 X-Touch smart triple-proof V-Mount battery X221 and 240W USB-C Charging Cable.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Product Dimensions | 145.2 x 92.0 x 91.5mm / 5.7 x 3.6 x 3.6in |
|---|---|
| Package Dimensions | 180.0 x 138.0 x 109.0mm / 7.1 x 5.4 x 4.3in |
| Product Weight | 1564 ± 10g / 55 ± 0.4oz |
| Package Weight | 1847 ± 10g / 65 ± 0.4oz |
| Material(s) | Flame-retardant PC, Silicone, Aluminum Alloy |
| Battery Type | Lithium-ion Battery |
| Rated Battery Parameters | 14.76V / 15,000mAh / 221.4Wh |
| Total Rated Output | 221W |
| Input | |
| USB-C1 / USB-C2 | 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓5A, 28V⎓5A; 140W (Max) |
| BP / D-Tap1 / D-Tap2 | 16.8V⎓12A (Max) |
| Output | |
| USB-A | 5V⎓3A, 9V⎓3A, 12V⎓2.5A; 30W (Max) |
| BP | 11.2-16.8V⎓15A |
| D-Tap1 / D-Tap2 | 11.2-16.8V⎓10A |
| 8V-OUT | 8V⎓3A (Max) |
| 12V-OUT | 12V⎓3A (Max) |
| Supported Protocols | |
| USB-C1 / USB-C2 | PD3.1, PD3.0, QC2.0, QC3.0, AFC, DCP-1.5A, PPS, APPLE-2.4A |
| USB-A | QC3.0, QC2.0, AFC, FCP, SCP, DCP-1.5A, APPLE-2.4A |
| Discharge Cut-off Voltage | 11.2V |
| Charging Temperature | 0°C to 45°C / 32°F to 113°F |
| Discharging Temperature | -15°C to 60°C / 5°F to 140°F |
| Charging Ports | BP, D-Tap, USB-C |
| Drop Resistance Rating | 1.5m (4.9ft) |
| Ingress Protection Rating | IP54 |
Product details
| Battery | Lithium-Ion |
|---|---|
| Battery Mount / Series | V-Mount |
| Batteries / Chargers | Batteries Only |
| Wattage | 221.4Wh |
In the box
- SmallRig 4985 X-Touch Smart Triple-Proof V-Mount Battery X221
- 240W USB-C Charging Cable
