Description
The Rode AI-1 USB Audio Interface sits in our Audio Input & Output range.
Highlights include high-speed USB-C Audio interface, 96 kHz / 24-Bit, single combo XLR-1/4" input and phantom Power for condenser Microphones.
Key specifications: weight 19.8 oz / 561.3 g; dimensions (D x W x H) 3.9 x 4.9 x 1.5" / 100.0 x 124.0 x 38.0 mm; computer connectivity USB Type-C; form factor Desktop; mic preamps 1.
An audio interface powers XLR microphones and converts their signal for recording on a computer. In the box: USB Cable, registration card for ableton live lite and limited 2-Year warranty.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Analogue Inputs and Outputs | Input: 1 x Neutrik XLR-1/4" / 6.35 mm combo Outputs: 2 x 1/4" / 6.35 mm (impedance balanced), 1 x 1/4" / 6.35 mm (headphones) |
|---|---|
| Computer Connectivity | USB Type-C |
| Form Factor | Desktop |
| Mic Preamps | 1 |
| Phantom Power | Yes |
| Bit Depth | 24-bit |
| Sample Rates | 44.1, 48, 88.2, 96 kHz |
| Zero-Latency Direct Monitoring | Yes |
| USB Bus Powered | Yes |
| OS Requirements | Mac OS X 10.10 or later Windows 7 or later |
| Dynamic Range | 104 dBu |
| Equivalent Noise | Equivalent Input Noise at Maximum Gain: -128 dBA (source impedance 150 ohms, 20 Hz to 20 kHz, A-weighted) |
| Frequency Response | 20 Hz to 20 kHz (better than ±1 dB, measured after ADC) |
| Gain Range | 0 to 45 dB |
| Input Impedance | XLR Mic Input: 1.3 kOhms Instrument Input: 0.9 MOhms |
| Monitor Outputs | Max Output Level: -6 dBu |
| Headphone Output | Max Output Power (at 1% THD): 32 Ohms, 24 mW, 300 Ohms, 245 mW |
| Dimensions (D x W x H) | 3.9 x 4.9 x 1.5" / 100.0 x 124.0 x 38.0 mm |
| Weight | 19.8 oz / 561.3 g |
In the box
- USB Cable
- Registration Card for Ableton Live Lite
- Limited 2-Year Warranty
