Description
The Focusrite Scarlett 4i4 USB-C Audio/MIDI Interface (4th Generation) sits in our Audio Input & Output range.
Highlights include singers, musicians, Podcasters/Streamers, Bus/External Power, Mac/Windows/iPadOS, 2 Mic/Line/Instrument preamps, 2 line in, headphone output, 4 line outputs and 24-Bit / 192 kHz AD/DA Conversion.
Key specifications: frequency response Inputs: 20 Hz to 20 kHz ±0.1 dB; dimensions 7.09 x 5.08 x 2.32" / 18.01 x 12.9 x 5.89 cm; channels of I/O Analogue: 4 Inputs / 4 Outputs at 192 kHz; maximum sampling rate 192 kHz / 24-Bit; number of microphone preamps 2 Preamps.
In the box: Focusrite scarlett 4i4 USB-C Audio/MIDI interface (4th generation), USB-C to USB-C Cable, USB-C to USB-A Adapter and USB-C Power supply. Manufacturer model number FOCMOSC0034.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Key Specs | |
|---|---|
| Analogue Audio I/O | 2 x XLR 3-Pin Balanced Mic/Line Input 2 x 1/4" TRS Balanced/Unbalanced Line/Hi-Z Input (Front Panel) 2 x 1/4" TRS Balanced Monitor Output 1 x 1/4" TRS Headphone Output (Front Panel) |
| Channels of I/O | Analogue: 4 Inputs / 4 Outputs at 192 kHz |
| Built-In DSP | None |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Preamps | 2 Preamps |
| Input Level Adjustment | 2 x Knob |
| Signal Processing | |
| Gain/Trim Range | Inputs: Up to +69 dB |
| Connectivity | |
| Phantom Power | 48 V, Selectable On/Off (Selectable on Individual Inputs) |
| Host Connection / USB | 1 x USB-C |
| Host Connection Protocol | USB 2.0 |
| USB (Non-Host) | 1 x USB-C (Power Input) |
| MIDI I/O | 1 x DIN 5-Pin Input 1 x DIN 5-Pin Output |
| Performance | |
| Frequency Response | Inputs: 20 Hz to 20 kHz ±0.1 dB |
| Maximum Output Level | Line/Monitor Outputs: +15.5 dBu at 0 dBFS Headphone Outputs: +7 dBu |
| Impedance | Mic Inputs: 3 Kilohms Hi-Z Inputs: 1.5 Megohms Line Inputs: 60 Kilohms Line Outputs: 430 Ohms Headphone Outputs: < 1 Ohm |
| Digital Audio | |
| Sample Rates | Up to 192 kHz |
| Bit Depths | 24-Bit |
| Audio Storage & Playback | |
| Memory Card Slot | None |
| Power | |
| Power Requirements | AC/DC Power Adapter (Included), USB Bus Power |
| AC/DC Power Adapter | 5 VDC at 3 A |
| Physical | |
| Dimensions | 7.09 x 5.08 x 2.32" / 18.01 x 12.9 x 5.89 cm |
| Weight | 1.7 lb / 0.8 kg (without Accessories) 2.2 lb / 1.0 kg (with Accessories) |
In the box
- Focusrite Scarlett 4i4 USB-C Audio/MIDI Interface (4th Generation)
- USB-C to USB-C Cable
- USB-C to USB-A Adapter
- USB-C Power supply
Reviews
There are no reviews yet.
