Description
The JBL Commercial Solutions Series CSS-H30 30W Paging Horn is an amplifier.
Key specifications: weight 4.5 lb (2.0 kg); material Horn: ABS; directivity factor 15.8 (2 kHz); directivity index 12 (2 kHz); power rating 30 W (120 W peak), 100 hours.
In the box: JBL Commercial Solutions Series CSS-H30 30W Paging Horn and stainless steel mounting bracket.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| System | |
|---|---|
| Frequency Response | -10 dB: 380 Hz to 6 kHz (based on average 1 kHz to 6 kHz sensitivity) |
| Coverage Pattern | 50° (H) x 70° (V) (at 2 kHz and averaged 1 kHz to 4 kHz) |
| High-Pass Filter | Included: Passive 350 Hz high-pass filter built-in to protect against damage from frequencies below operational range |
| Directivity Factor | 15.8 (2 kHz) |
| Directivity Index | 12 (2 kHz) |
| Power Rating | 30 W (120 W peak), 100 hours |
| Sensitivity | 1 W, 2.83 V @ 3.3' (1.0 m): 108 dB, average 1 kHz to 6 kHz; 112 dB at 2 kHz |
| Maximum SPL | 3.3' (1.0 m): 123 dB continuous averaged (129 dB peak), 1 kHz to 6 kHz 127 dB continuous average (133 dB peak), 1.4 kHz, 30 W input, 8 Ω setting |
| Nominal Impedance | 30 W / 70 V, NC / 100 V Tap: 167 Ω 15 W / 70 V, 30 W / 100 V Tap: 333 Ω 7.5 W / 70 V, 15 W / 100 V Tap: 667 Ω 3.8 W / 70 V, 7.5 W / 100 V Tap: 1333 Ω 1.9 W / 100 V, 3.8 W / 100 V Tap: 2666 Ω 8 Ω at 8 Ω direct setting |
| Transformer Taps | 70 V: 30 W, 15 W, 7.5 W, 3.8 W, 1.9 W 100 V: 30 W, 15 W, 7.5 W, 3.8 W |
| Transducers | |
| Driver | Full-Range: 1.5" (3.8 cm) diameter with phenolic diaphragm |
| Physical | |
| Material | Horn: ABS |
| Mounting Hardware | Stainless steel powder-coated U-bracket (yoke) with 3 x 0.41" (1.04 cm) diameter mounting holes; stainless steel exterior hardware |
| Input Connection Type | 12" (30 cm) pigtail to bare wire; entrance via water-tight fitting Wire colours: Red: Positive (+); Black: Negative (-) |
| Environmental | IP65 rating per IEC529, salt spray per B117, stainless steel U-bracket and exterior hardware |
| Safety Agency Approvals | Transformer UL registered per UL1876 "Isolating Signal and Feedback Transformers for Use in Electronic Equipment" |
| Dimensions (H x W x D) | Horn Only: 8.2 x 11.2 x 11.3" (20.6 x 28.5 x 28.7 cm) With Mounting Bracket: 8.9 x 11.2 x 11.3" (22.4 x 28.5 x 28.7 cm) (depth excludes cable exit) |
| Weight | 4.5 lb (2.0 kg) |
In the box
- JBL Commercial Solutions Series CSS-H30 30W Paging Horn
- Stainless Steel Mounting Bracket
