Description
The dbx DriveRack PA2 Complete Loudspeaker Management System is a processor.
Highlights include Mac, PC, iOS & Android mobile control, crossover for 2- or 3-Way Systems, AutoEQ automatic room AEQ function and automatic feedback suppression.
Key specifications: frequency response 20 Hz to 20 kHz, (+0 /- 0.5 dB); weight 2.4 kg; dimensions (H x D x W) / 44.5 x 146.1 x 482.6 mm; internal processing 32-bit floating point; sample rate 48 kHz.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Analogue Inputs | Number of Inputs: 2 x line inputs, 1 x RTA mic input Connectors: 2 x female XLR line inputs, 1 x female XLR RTA mic input Type: Electronically balanced/RF filtered Impedance: > 50 kOhms Max Input Level (line inputs): > +20 dBu CMRR: > 45 dB RTA Mic Preamp Phantom Power: +15 VDC |
|---|---|
| Analogue Outputs | Number of Outputs: 6 x line outputs Connectors: Male XLR Type: Electronically balanced, RF filtered Impedance: 120 Ohms Max Output Level: +20 dBu Alignment Delay: Up to 10 ms per output channel pair |
| A/D and D/A Conversion | A/D Performance A/D Convertor: 24-bit with dbx Type IV Conversion System A/D Dynamic Range: 112 dB A-weighted, 110 dB unweighted Type IV Dynamic Range: 123 dB with transient material, A-weighted, 22 kHz BW 121 dB with transient material, unweighted, 22 kHz BW 115 dB typical with programme material, A-weighted, 22 kHz BW D/A Performance D/A Convertor: 24-bit D/A Dynamic Range: 112 dB A-weighted, 110 dB unweighted |
| Internal Processing | 32-bit floating point |
| Sample Rate | 48 kHz |
| Dynamic Range | A-Weighted: 110 dB Unweighted: 107 dB |
| THD + N | 0.003% typical at +4 dBu, 1 kHz, 0 dB input gain |
| Frequency Response | 20 Hz to 20 kHz, (+0 /- 0.5 dB) |
| Crosstalk | Interchannel Crosstalk: < -110 dB, -120 dB typical (input-to-output: < -100 dB) |
| Latency | Input to output: 1.847 ms |
| Power | Operating Voltage: 100 to 120 VAC 50/60 Hz or 220 to 240 VAC 50/60 Hz Power Consumption: 22 W |
| Dimensions (H x D x W) | / 44.5 x 146.1 x 482.6 mm |
| Weight | 2.4 kg |
In the box
- dbx DriveRack PA2 Complete Loudspeaker Management System
