Description
The Shimbol TP Mini 600' HDMI Wireless Video System sits in our Wireless Video Systems range.
Highlights include transmitter and receiver set, transmit up to 1080p60 video, transmit up to 600' line of sight, HDMI input and outputs and L-Series battery plate on each unit.
Key specifications: mounting Not Specified by Manufacturer; frequency range 5 GHz; battery type Transmitter/Receiver: 1x L-Series; weight Transmitter/Receiver: 4.2 oz / 120 g; material of construction Aluminium.
In the box: Shimbol TP mini 600' HDMI wireless video transmission system, transmitter, receiver, USB-C Power Cable and sticker.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Key Specs | |
|---|---|
| Video I/O | Transmitter: 1x HDMI (Unspecified Signal) Input Transmitter: 1x HDMI (Unspecified Signal) Output Receiver: 2x HDMI (Unspecified Signal) Output |
| Embedded Audio | HDMI |
| Latency | 70 ms |
| Video Format | HDMI 1080p: 60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Battery Type | Transmitter/Receiver: 1x L-Series |
| Power Consumption | Transmitter: 2.5 W Receiver: 2 W |
| Mounting | Not Specified by Manufacturer |
| Inputs / Outputs | |
| Audio I/O | No |
| Power I/O | Transmitter/Receiver: 1x USB-C (5 VDC) Input Transmitter/Receiver: 1x USB-C (5 VDC) Input |
| Encryption | No |
| Wireless | |
| Wireless Range | 600' / 182.9 m (Line-of-Sight) |
| Channel Bandwidth | 40 MHz, 20 MHz |
| Frequency Range | 5 GHz |
| RF Power | < 17 dBm |
| RF Sensitivity | -85 dBm |
| Wi-Fi | No |
| Bluetooth | No |
| Mobile App Compatible | No |
| Cellular Support | No |
| Format Support | |
| Audio Format | Not Specified by Manufacturer |
| Timecode Support | No |
| Environmental | |
| Environmental Resistance | No |
| Certifications | No |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| General | |
| Material of Construction | Aluminium |
| Dimensions | Transmitter/Receiver: 4.1 x 2.5 x 0.6" / 103 x 63.5 x 15 mm |
| Weight | Transmitter/Receiver: 4.2 oz / 120 g |
In the box
- Shimbol TP Mini 600' HDMI Wireless Video Transmission System
- Transmitter
- Receiver
- USB-C Power Cable
- Sticker
