Description
The Sennheiser EK IEM G4 Stereo Bodypack Receiver with IE 4 Earphones (B: 626 - 668 MHz) sits in our Receivers & Transmitters range.
Highlights include B Band (626 to 668 MHz), 1 x pair of IE 4 earphones, up to 16 compatible channels and 42 MHz Bandwidth.
Key specifications: weight 125 g; dimensions (W x L x H) 82 x 64 x 24 mm; frequency band B: 626 to 668 MHz; switching bandwidth Up to 42 MHz; Nominal/Peak deviation ±24 kHz / ±48 kHz.
In the box: Sennheiser EK IEM G4 stereo bodypack receiver with IE 4 earphones (B: 626 to 668 MHz), 2 x AA Batteries and IE 4 In-Ear Stereo Earphones for Wireless Monitor Applications.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Receiver | |
|---|---|
| Frequency Band | B: 626 to 668 MHz |
| Receiving Frequency | Maximum 1680 receiving frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 16 factory-preset channels, no intermodulation 6 frequency banks with up to 16 programmable channels |
| Switching Bandwidth | Up to 42 MHz |
| Nominal/Peak Deviation | ±24 kHz / ±48 kHz |
| Receiver Type | Adaptive diversity |
| Sensitivity | < 4 μV, typ. 1.6 μV for 52 dBA (with HDX, peak deviation) rms s/n |
| Adjacent Channel Selectivity | Typically ≥ 65 dB |
| Intermodulation Attenuation | Typically ≥ 70 dB |
| Blocking | ≥ 80 dB |
| Pilot Tone | Squelch: Can be switched off |
| Squelch | 5 to 25 dBµV, adjustable in steps of 2 dB |
| Compander | Sennheiser HDX |
| Signal to Noise Ratio | Approximately 90 dBA (1 mV, peak deviation) |
| Total Harmonic Distortion (THD) | ≤ 0.9 % |
| Audio Output Power | 2 x 100 mW at 32 Ohms (@ 2.4 V, 5 % THD, nominal deviation) |
| Quality Setting Range | +8 dB at 80 kHz |
| Limiter | -18 dB to -6 dB, adjustable in steps of 6 dB, can be switched off |
| Temperature Range | 14 to 131°F / -10 to 55°C |
| Power Supply | 2 x AA batteries, 1.5 V or BA 2015 accupack |
| Current Consumption | At Nominal Voltage: Approximately 140 mA With Transmitter Switched Off: ≤ 25 µA |
| Operating Time | Approximately 4 to 6 hours (depending on volume level) |
| Dimensions (W x L x H) | 82 x 64 x 24 mm |
| Weight | 125 g |
In the box
- Sennheiser EK IEM G4 Stereo Bodypack Receiver with IE 4 Earphones (B: 626 to 668 MHz)
- 2 x AA Batteries
- IE 4 In-Ear Stereo Earphones for Wireless Monitor Applications
