Description
The IK Multimedia iRig Stream Audio Interface sits in our Audio Input & Output range.
Highlights include stereo line input over RCA connectors, Audio level LED indicators to dial in the right gain fast, up to 48kHz / 24bit resolution for crystal clear sound, pre-mixes audio sources down to stereo or mono and loop-back mixes incoming signals with your device’s audio.
Key specifications: frequency response 20 Hz - 20kHz; connector 2x RCA (unbal.) Left/Right; weight 65g/2.29oz; conversion 24-bit A/D, 24-bit D/A; sampling rate 44.1 kHz, 48 kHz.
An audio interface powers XLR microphones and converts their signal for recording on a computer. In the box: iRig Stream interface, Lightning to mini-DIN connection cable (60cm/23.62"), USB C-Type to mini-DIN connection cable (60cm/23.62") and USB A-Type to mini-DIN connection cable (60cm/23.62"). Manufacturer model number IP-IRIG-STREAM-IN.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Conversion | 24-bit A/D, 24-bit D/A |
|---|---|
| Sampling Rate | 44.1 kHz, 48 kHz |
| Power | USB bus powered or DC IN. When connected to an external PSU (iRig PSU 3A, not included), iRig Stream charge the connected iOS lightning device. |
| Metering | 3x LEDs |
| Device Connection | mini-DIN |
| Connector | 2x RCA (unbal.) Left/Right |
| Nominal Input Level | -10dBV |
| Input Impedance | 16.5kOhms |
| Frequency Response | 20 Hz - 20kHz |
| Connector | 1/8” TRRS jack (CTIA wiring standard) |
| Supply voltage | > 2,5V |
| Microphone gain | Adjustable with numbered thumbwheel |
| Headphone Level control | numbered thumbwheel |
| Headphone Output Power | 100mW into 50Ohms |
| Size | 105.5mm/4.15" x 44.5mm/1.75" x 24mm/0.94" |
| Weight | 65g/2.29oz |
In the box
- iRig Stream interface
- Lightning to mini-DIN connection cable (60cm/23.62")
- USB C-Type to mini-DIN connection cable (60cm/23.62")
- USB A-Type to mini-DIN connection cable (60cm/23.62")
