Description
The Atomos Sumo PRO-19 4K HDR Monitor Recorder Switcher is a production monitor.
Highlights include 3840 x 2160 HDR touchscreen display, HDMI 2.0 and 12G-SDI Inputs/Outputs, CFexpress type B slot, USB-C recording, quad-split or switch between 4 inputs and 1200 cd/m² brightness, high Bright mode.
Key specifications: weight 15.7 lb / 7.1 kg; dimensions 18.7 x 12.4 x 2.4" / 47.4 x 31.5 x 6.2 cm; screen size 19"; material of construction Aluminium, Plastic; panel type IPS-Type LCD.
An external recorder captures higher-quality codecs than many cameras record internally. In the box: Atomos sumo PRO-19 4K HDR Monitor recorder switcher, 4-Pin XLR Power Supply, antenna tip set (Black, white, yellow, green, red), 2 x Wi-Fi Antenna, AirGlu antenna and 3 x Antenna Cap and 4 more items.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Display | |
|---|---|
| Panel Type | IPS-Type LCD |
| Display Size | 19.00" / 48.3 cm |
| Native Resolution | 3840 x 2160 |
| Aspect Ratio | 16:9 |
| Touchscreen | Yes |
| Maximum Brightness | 1200 nits / cd/m 2 |
| Colour Support | 1.07 Billion Colours (8-Bit+FRC) |
| HDR Support | Yes |
| Colour Gamut | 100% Rec. 709 99% DCI-P3 99% NTSC 87% Rec. 2020 |
| LUT Support | Yes |
| Image Controls | Anamorphic De-Squeeze, False Colour, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra |
| Inputs/Outputs | |
| Video I/O | 2x BNC (12G-SDI) Input 2x BNC (3G-SDI) Input 1x BNC (12G-SDI) Output 1x HDMI 2.0 Input 1x HDMI 2.0 Output 2x USB-C 3.0 / 3.1/3.2 Gen 1 Output |
| Embedded Audio | HDMI: 8-Channel SDI: 12-Channel |
| Audio I/O | 2x XLR Input 2x XLR Output 1x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | No |
| Power I/O | 1x XLR 4-Pin Input |
| Other I/O | 1x BNC (LTC) Input 1x 2.5 mm (LANC) Input 1x RJ45 (Gigabit Ethernet) Input/Output |
| Media/Memory Card Slot | Single Slot: CFexpress Type B [Record/LUT/Firmware] |
| Wireless | |
| Wi-Fi | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Mobile App Compatible | No |
| Format Support | |
| Video Format | SDI (8/10-Bit 4:2:2) 8K Raw: 30 6K Raw: 30 4K Raw: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 2K Raw: 240/120/60/50/30/25/24 1080p: 120/60/50/30/25/24 1080i: 60/50 720p: 60/50 HDMI (8/10-Bit 4:2:2) DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 120/60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Video Signal Conversion | HDMI to SDI DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 120/60/50/30/25/24 1080i: 60/50 720p: 60/50 SDI to HDMI DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 120/60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Timecode Support | Yes |
| Recording | |
| Pulldown Conversion | 2:2, 3:2 |
| Camera Trigger | SDI, HDMI |
| Pre-Roll Record | Full HD: 8 Seconds 4K: 2 Seconds |
| Encoding Formats | Up to 4096 x 2160 ProRes 422, 422 HQ, HQ, LT, Raw, Raw HQ at up to 60 fps DNxHD 36, 145, 220x at up to 60 fps DNxHR HQ, HQX, LB, SQ at up to 60 fps H.265 HQ, LQ, MQ, SQ 8/10-Bit at up to 60 fps |
| Maximum Audio Tracks | 12 |
| Phantom Power | +48 V |
| Power | |
| Input Power | 12 to 16 VDC |
| Battery | Interchangeable Mount (No Plate Included) |
| Power Consumption | 75 W |
| Mounting | |
| VESA Mounting-Hole Pattern | 100 x 100 mm |
| Tripod/Accessory Mounting | Top 4x 1/4"-20 Female 2x 3/8"-16 Female Bottom 6x 1/4"-20 Female 3x 3/8"-16 Female Right 4x 1/4"-20 Female 2x 3/8"-16 Female Left 2x 1/4"-20 Female 1x 3/8"-16 Female |
| General | |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| Material of Construction | Aluminium, Plastic |
| Dimensions | 18.7 x 12.4 x 2.4" / 47.4 x 31.5 x 6.2 cm |
| Weight | 15.7 lb / 7.1 kg |
Product details
| Screen Size | 19" |
|---|---|
| Screen Resolution | 3840 x 2160 |
In the box
- Atomos Sumo PRO-19 4K HDR Monitor Recorder Switcher
- 4-Pin XLR Power Supply
- Antenna Tip Set (Black, White, Yellow, Green, Red)
- 2 x Wi-Fi Antenna
- AirGlu Antenna
- 3 x Antenna Cap
- Desktop Feet Set
- Hex Wrench
- Cleaning Cloth
- Screw Set
