Description
The YoloLiv YoloBox Ultra is an all in one live streaming encoder and monitor for creators and production teams who need to switch multiple video sources, record, and stream from a compact unit. It suits live events, studio setups, and mobile productions where HDMI cameras, USB sources, and network streaming need to be managed from one device.
It provides 4 HDMI inputs, USB-A and USB-C video input support, HDMI out, and Ethernet connectivity. It handles live input resolutions up to 4K 30fps and 1080p up to 60fps, with H.264 and H.265 encoding. Streaming protocols include RTMP, RTMPS, MJPEG and SRT, and it supports ISO recording and network bonding. The built-in battery is 6800mAh, with USB-C power input.
In use, it connects to cameras, computers, webcams, capture sources and network links, then sends a program feed to a display or streaming platform. It can work with HDMI, USB and wired network setups, depending on the production. The box includes the YoloBox Ultra, screen protector, user manual, 2x USB-C charger cable, hotshoe mount and SIM card eject pin.
Specifications
| Input Power | DC5V/9V/, 12V/15V |
|---|---|
| Power Consumption | 45W |
| Power Supply | USB Type-C |
| USB Rated Output | USB-A:5V/1A |
| Battery Capacity | 6800mAh |
| Monitor Screen Size | 8inch LCD Resolution: 1200 x 1920; Brightness: 650nits; Contrast ratio(1500:1), Viewing Angle (full viewing Angle), NTSC 80% |
| Local Video Inputs | HDMI,USB-A |
| Video Over Ethernet | RTMP/RTMPS/SRT |
| Video Input Connectors | HDMI,USB-A,RJ-45,USB Type-C |
| Video Input Aspect Ratios | 16:9; 4:3; 1:1 |
| Video Input Deinterlacing | No |
| Live Broadcast Video input Resolution | 480p/720p/1080p(up to 60fps)/4k 30fps |
| Video Encoded Format | H.264 H.265 |
| Video processing Bitrate control | CQ, VBR, CBR |
| Hardware-Accelerated Video Encoding | Optional |
| Video Output Signal Types | FLV-RTMP,HDMI,UVC |
| Video Output Connectors | HDMI OUT, USB-C |
| Video Output Streaming protocols | RTMP, RTMPS, MJPEG, SRT |
| Live Broadcast Video Output Resolution | 480p/720p/1080p(up to 60fps)/4k 30fps |
| Analog Audio Input Connectors | Line In, Mic In, 3.5mm |
| Digital Audio Inputs | USB, HDMI, RTMP(From internet), Local video(From SD card) |
| Digital Audio Input Connectors | USB-A, HDMI, USB-C |
| Audio Input Mute | Yes |
| Audio Input Format | 32KHZ/44.1KHZ/48KHZ :16bit |
| Audio Encoded Format | (AAC)44.1K/48KHZ 2Ch 16bit |
| Analog Audio Output | 3.5mm headphone jack |
| Digital Audio Outputs | HDMI audio (Embedded), USB Audio (Embedded) |
| Record Formats | MP4 |
| Wi-Fi | 2.4G/ 5G（Support WiFi6） |
| USB Communication Standard | USB 2.0 and USB 3.0 |
| Ethernet Data Rate | 10/100/1000M, half/full duplex with autodetect |
| SIM Card Size | Nano-SIM Card |
| SDCard format | FAT32(Under 128G), NTFS, EX-FAT |
| Operating Temperature | 0℃-40℃ |
| Operating Humidity | 15%-85%, No Condensation |
| Country of Origin | Made in China |
In the box
- YoloBox Ultra
- Screen Protector
- YoloBox Ultra User Manual
- 2x USB-C Charger Cable
- Hotshoe Mount
- SIM Card Eject Pin
