Description
The SmallHD CINE 5 Touchscreen On-Camera Monitor is a production monitor.
Highlights include 5" 1920 x 1080 touchscreen display, 2000 cd/m², 10-Bit LCD Panel, DCI P3, 2-Pin locking Power input, 5-Pin locking USB for RED Camera control and side-mounted joystick, back button.
Key specifications: mounting 4 x 1/4"-20 Female; screen size 5"; resolution 1920 x 1080; material of construction Aluminium; panel type LCD.
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks. Manufacturer model number 33.1.16-0526.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Display | |
|---|---|
| Panel Type | LCD |
| Display Size | 5.0" / 12.7 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Touchscreen | Yes |
| Maximum Brightness | 2000 cd/m 2 |
| Bit Depth / Colour Support | 10-Bit (1.07 Billion Colours) |
| Pixels Per Inch (ppi) | 440 ppi |
| Colour Gamut | 100% DCI-P3 |
| Image Controls | Anamorphic De-Squeeze, False Colour, Focus Peaking, Histogram, Pixel-to-Pixel Zoom, RGB Parade, Vectorscope, Waveform, Zebra |
| Video | 1 x HDMI Type A (HDMI 2.0) Input 1 x HDMI Type A (HDMI 2.0) Loop Output 1 x BNC (3G-SDI) Input 1 x BNC (3G-SDI) Loop Output |
| Embedded Audio | HDMI: 8-Channel SDI: 8-Channel |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | None |
| Power I/O | 1 x LEMO 2-Pin (34 VDC) Input |
| Other I/O | 1 x LEMO 5-Pin 2.0 Output |
| Media/Memory Card Slot | None |
| Format Support | |
| Video Format | HDMI (8/10/12/16-Bit 4:4:4/4:2:2 YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 120/119.88/100/60/59.94/50 720p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98 576p: 200/100/50 480p: 240/239.76/120/119.88/100/60/59.94 480i: 240/239.76/120/119.88/100/60/59.94 576i: 200/100/50 SDI (10-Bit 4:2:2 YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 120/119.88/100/60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 576i: 50 480i: 59.94 |
| Video Signal Conversion | SDI to HDMI UHD 4K: 30/29.97/25/24/23.98 1080p: 119.88/100/60/59.94/50/30/29.97/25/24/23.98 1080i: 120/119.88/100/60/59.94/50 720p: 240/239.76 HDMI to SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 120/119.88/100 720p: 60/59.94/50/30/29.97/25/24/23.98 480i: 59.94 576i: 50 |
| Mounting | |
| Mounting | 4 x 1/4"-20 Female |
| General | |
| Material of Construction | Aluminium |
Product details
| Screen Size | 5" |
|---|---|
| Screen Resolution | 1920 x 1080 |
In the box
- SmallHD CINE 5 Touchscreen On-Camera Monitor
