Description
Rolls RPQ160b - Parametric Equalizer: an equaliser.
Highlights include single channel, 4-Bands, high and low pass filters, XLR, 1/4" and RCA I/O and AC adapter included.
Key specifications: frequency response 16 Hz to 30 kHz, +/-3.0 dB; weight 2.3 kg; dimensions (WxDxH) 19 x 4 x 1.75" (483 x 100 x 45 mm); inputs 1 x XLR 1 x 1/4" TRS phone 1 x RCA; filter type Parametric.
In the box: Rolls RPQ160b - parametric equalizer and external Power supply.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Filter Type | Parametric |
|---|---|
| Number of Channels | Single |
| Inputs | 1 x XLR 1 x 1/4" TRS phone 1 x RCA |
| Outputs | 1 x XLR 1 x 1/4" TRS phone 1 x RCA |
| Maximum Input Level | +24 dB |
| Frequency Bands | 70 Hz to 1.5 kHz 150 Hz to 3 kHz 300 Hz to 10 kHz 600 Hz to 20 kHz |
| Bandwidth | 0.3 to 3 octaves per band |
| Range (Boost/Cut) | -15 dB to +15 dB per band |
| Maximum Output Level | +24 dB |
| Frequency Response | 16 Hz to 30 kHz, +/-3.0 dB |
| Noise | SNR: >90 dB |
| Power Requirements | 12 VAC via supplied adapter |
| Dimensions (WxDxH) | 19 x 4 x 1.75" (483 x 100 x 45 mm) |
| Weight | 2.3 kg |
| Specialities | High-pass filter: 16 Hz to 500 Hz, 12 dB/octave slope Low-pass filter: 1 kHz to 30 kHz, 12 dB/octave slope |
In the box
- Rolls RPQ160b - Parametric Equalizer
- External Power Supply
