Description
Neumann KH 120-II Single Studio Monitor (Anthracite): a powered speaker.
Highlights include DSP engine included, higher SPL, better resolution, linear frequency and phase response and even deeper bass.
Key specifications: output power woofer amplifier (THD+N with limiter deactivated: 10%) 145 W; free field frequency response ±3 dB 44 Hz ... 21 kHz; Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu) <20 dB(A) SPL; Max. SPL calc. in half space at 3% THD at 1m (averaged between 100 hz and 6 kHz) 116.8 dB SPL; acoustical principle Bassreflex, Ports at the front.
Studio monitors are designed for an even, uncoloured response so mixes translate to other speakers. In the box: 1 x Neumann KH 120-II Single Studio Monitor (Anthracite), 1 x Mains Cable, 4 x Self-adhesive feet, 1 x Safety Guide and 1 x Supplement “Getting Started Quickly”.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Free field frequency response ±3 dB | 44 Hz ... 21 kHz |
|---|---|
| Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu) | <20 dB(A) SPL |
| Max. SPL calc. in half space at 3% THD at 1m (averaged between 100 Hz and 6 kHz) | 116.8 dB SPL |
| Acoustical Principle | Bassreflex, Ports at the front |
| Analog input(s) | XLR: analog electronically balanced |
| Analog input impedance | 24k Ohms |
| Digital input(s) | RCA (75 Ω): S/PDIF |
| Input gain control (sensitivity) | 0 dB ... -15 dB |
| Output level control (output level in 1 m based on 0 dBu input level) | 94; 100; 108; 114 dB SPL |
| Equalisation: Bass | 0; -2; -4; -6 dB |
| Equalisation: Low-Mid | 0; -2; -4; -6 dB |
| Equalisation: Treble | +1; 0; -1; -2 dB |
| Control | Local; Network |
| Crossover frequency | 1.7 kHz |
| FIR phase correction | Linear phase (120 Hz ... 16 kHz; +/- 45°) |
| Protection circuitry | Independent soft clip, peak and thermo limiters for woofer and tweeter; Woofer excursion limiter; thermo limiter for the electronics and amplifiers |
| Output power woofer amplifier (THD+N with limiter deactivated: 10%) | 145 W |
| Output power tweeter amplifier (THD+N with limiter deactivated: 10%) | 100 W |
| Woofer | 130 mm (5.25") with protecting metal grille |
| Tweeter | 25 mm (1") with protecting metal grille |
| Product dimensions (height x width x depth) | 287 x 182 x 227 mm |
| Product weight | 5.4 kg |
In the box
- 1 x Neumann KH 120-II Single Studio Monitor (Anthracite)
- 1 x Mains Cable
- 4 x Self-adhesive feet
- 1 x Safety Guide
- 1 x Supplement “Getting Started Quickly”
