Description
Netgear AV Line M4250 GSM4210PD 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (110W): a network switch.
Highlights include 8 x gigabit ethernet PoE+ ports, 1 x gigabit RJ45 slot, 1 x gigabit SFP slot, 20 Gb/s switching capacity and 14.88 mpps forwarding rate.
Key specifications: weight 6.28 lb / 2.85 kg; dimensions 8.3 x 5.5 x 1.6" / 210 x 140 x 40 mm; material of construction Metal; layer services supported Layer 2 Support, Layer 3 Support; jumbo frames support 12,000 Bytes.
In the box: Netgear AV line M4250 GSM4210PD 8-Port gigabit PoE+ compliant managed AV switch with SFP (110W), Power adapter (130W), Power cable, console USB-C to USB-A 2.0 console cable, flat brackets & screws for desktop or wall mounting and rubber footpads for tabletop installation and 1 more items. Manufacturer model number GSM4210PD-100AUS.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Interfaces | |
|---|---|
| Inputs/Outputs | 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ 1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) 1 x 10/100/1000 Mb/s Gigabit SFP (Uplink) 1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Console) 1 x USB-C (Console) 1 x USB-A |
| Protocols | |
| Layer Services Supported | Layer 2 Support, Layer 3 Support |
| Supported Protocols | DHCP Server IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring SNMPv1 SNMPv2c SNMPv3 |
| Jumbo Frames Support | 12,000 Bytes |
| MAC Address Table Size | 16K |
| VLAN Groups | 256 |
| Security | |
| Security Features | DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control |
| SNMP Support | 1, 2, 3 |
| Standards | |
| Supported IEEE Standards | 802.1ab, 802.1ak, 802.1as, 802.1d, 802.1p, 802.1q, 802.1qat, 802.1qav, 802.1s, 802.1v, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ac, 802.3ad, 802.3af, 802.3at, 802.3u |
| Performance | |
| Latency | 2.2 µs |
| Forwarding Rate | 14.88 Mpps |
| Switching Bandwidth | 20 Gb/s |
| Packet Buffer | 16 Mb |
| Computer | |
| CPU | Up to 1.25 GHz A9 Single-Core |
| Memory | 2 GB |
| Electrical | |
| Power Draw | 132.25 W (Max) 6.4 W (Standby) |
| PoE Power Budget | 110 W |
| PoE per Port | 30 W |
| Power Supply Type | Internal |
| Environmental | |
| Operating Temperature | 32 to 77°F / 0 to 45°C |
| Operating Humidity | 90% |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
| Storage Humidity | 95% |
| Operating Altitude | 10,000' / 3048 m |
| Storage Altitude | 10,000' / 3048 m |
| General | |
| Cooling System | Passive |
| Mean Time Between Failures (MTBF) | 501,447 Hours |
| Material of Construction | Metal |
| Indicator Lights | Link/Activity/Speed, PoE |
| Rack Form Factor | 1 RU |
| Dimensions | 8.3 x 5.5 x 1.6" / 210 x 140 x 40 mm |
| Weight | 6.28 lb / 2.85 kg |
In the box
- Netgear AV Line M4250 GSM4210PD 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (110W)
- Power Adapter (130W)
- Power Cable
- Console USB-C to USB-A 2.0 Console Cable
- Flat Brackets & Screws for Desktop or Wall Mounting
- Rubber footpads for Tabletop Installation
- Rubber Cap for SFP Socket
