Description
Lilliput RM7026-12G Dual 7" 3RU Rackmount 12G-SDI Monitor: a production monitor.
Highlights include up to 1000 nits brightness, 12G-SDI/HDMI 2.0 Supported, lan connection, remote controllable via computer and 1920 x 1200 resolution.
Key specifications: connection SDI; brightness 1000 Nits; weight 1.83kg (4lbs); screen size 7"; panel 2x7" LTPS.
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks. In the box: Lilliput RM7026-12G dual 7" 3RU rackmount 12G-SDI Monitor, 12V 3A DC Power Adapter, tally connecter and E-User Manual.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Display | |
|---|---|
| Panel | 2x7" LTPS |
| Physical Resolution | 1920x1200 |
| Aspect Ratio | 16:10 |
| Brightness | 1000 Nits |
| Contrast | 1200:1 |
| Viewing Angle | 160° / 160° (H/V) |
| HDR Supported | HLG; ST2084 300/1000/100000 |
| HDMI Input | 1 (HDMI 2.0) |
| 12G-SDI Input | 1 |
| HDMI Output | 1 (HDMI 2.0) |
| 12G-SDI Output | 1 |
| Supported Formats | |
| HDMI | 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60... |
| 12G-SDI | 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60... |
| Audio In/Out | |
| Audio Channel | HDMI 8ch / SDI 16ch |
| Ear Jack | 3.5mm - 2ch 48kHz 24-bit |
| Power | |
| Input Voltage | DC 12-24V |
| Power Consumption | ≤21W (12V) |
| Environment | |
| Operating Temperature | 0°C - 50°C (32°F - 122°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Dimensions | |
| Dimensions | 480mm x 131.6mm x 32.5mm (18.9 in x 5.18 in x 1.3 in) |
| Weight | 1.83kg (4lbs) |
Product details
| Screen Size | 7" |
|---|---|
| Connection | SDI |
| Screen Resolution | 1920 x 1200 |
In the box
- Lilliput RM7026-12G Dual 7" 3RU Rackmount 12G-SDI Monitor
- 12V 3A DC Power Adapter
- Tally Connecter
- E-User Manual
