Description
The OBSBOT UVC to HDMI Adapter is a compact converter for turning a UVC camera signal into HDMI output. It suits users who want to connect a compatible OBSBOT camera or other UVC device to an HDMI display, monitor or capture setup. Its low-latency design and plug-and-play setup make it useful for live viewing, monitoring and conferencing.
It provides 1 x USB-C charging-only female input, 1 x USB-A female input, 1 x USB-C input and 1 x HDMI 2.0 output. Up to 4K60 output is supported, with firmware upgrade support included. Power is supplied by USB, with DC input power rated at 5 / 9 VDC at 2 A. The unit is black, measures 90.5 x 55.5 x 27.2 mm and weighs 78 g.
In use, the adapter sits between a UVC source and an HDMI screen or device. It is intended for cameras and other UVC-compatible equipment, with a USB-C cable included for connection. The box includes the OBSBOT UVC to HDMI Adapter and a 1.5 m USB-C cable.
Specifications
| Inputs / Outputs | |
|---|---|
| USB I/O | 1 x USB-C (Charging Only) Female Input 1 x USB-A Female Input |
| Video I/O | 1 x USB-C Input 1 x HDMI 2.0 Output |
| Power | |
| Power Source | USB (Not Included) |
| DC Input Power | 5 / 9 VDC at 2 A |
| Environmental | |
| Operating Temperature | 32 to 87°F / 0 to 55°C |
| Operating Humidity | 20 to 55% |
| Physical | |
| Colour | Black |
| Dimensions | 3.6 x 2.2 x 1.1" / 90.5 x 55.5 x 27.2 mm |
| Weight | 2.8 oz / 78 g |
In the box
- OBSBOT UVC to HDMI Adapter
- USB-C Cable (1.5m)
