Description
The Blackmagic Design Videohub 10x10 12G Zero-Latency Video Router.
Highlights include zero-latency routing switcher, 10 x 12G-SDI Inputs/10 x 12G-SDI outputs, supports up to DCI 4K60 video, combines SD, HD, UHD 4K & DCI 4K video and push-button, knob & ethernet control.
Key specifications: weight 6.64 lb / 3.01 kg; dimensions 19 x 9.3 x 1.74" / 48.3 x 23.6 x 4.42 cm; switching type Pushbutton, Software; processing resolution DCI 4K at 60; audio processing 48 kHz / 24-Bit.
Manufacturer model number VHUBSMAS12G1010.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Processing | |
|---|---|
| Switching Type | Pushbutton, Software |
| Processing Resolution | DCI 4K at 60 |
| Colour Processing | 8-Bit 4:2:2 10-Bit 4:2:2 12-Bit 4:4:4 |
| Audio Processing | 48 kHz / 24-Bit |
| Input | |
| Video Inputs | 10 x BNC (12G-SDI) |
| Input Video Format | SDI (10/12-Bit 4:4:4 RGB, YUV) DCI 4K up to 30 fps UHD 4K up to 30 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps SDI (10-Bit 4:2:2 RGB, YUV) DCI 4K up to 60 fps UHD 4K up to 60 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Embedded Audio Input | SDI |
| Output | |
| Video Outputs | 10 x BNC (12G-SDI) |
| Output Video Format | SDI (10/12-Bit 4:4:4 RGB, YUV) DCI 4K up to 30 fps UHD 4K up to 30 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps SDI (10-Bit 4:2:2 RGB, YUV) DCI 4K up to 60 fps UHD 4K up to 60 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Embedded Audio Output | SDI |
| Connectivity | |
| Other I/O | 1 x RJ45 LAN 1 x USB-C |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/424M/425M-A/425M-B/ST-2081-1/ST-2081-10/ST-2082-10 ITU -R BT.601/BT.656 |
| Display | |
| Display Size | 2.2" |
| Hardware | |
| OS Compatibility | macOS 12.0 macOS 13.0 or Later Windows 10 (64-Bit Only) Windows 11 *As of April, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Wi-Fi | None |
| Bluetooth | None |
| Power | |
| Power I/O | 1 x IEC C14 (100 to 240 VAC) Input |
| Power Consumption | 20.8 W |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 0 to 90% (Non-Condensing) |
| General | |
| Rack Form Factor | 1 RU |
| Dimensions | 19 x 9.3 x 1.74" / 48.3 x 23.6 x 4.42 cm |
| Weight | 6.64 lb / 3.01 kg |
In the box
- Blackmagic Design Videohub 10x10 12G Zero-Latency Video Router
