Description
The Blackmagic Design HyperDeck Studio HD Pro is a video recorder.
Highlights include 2 x 2.5" SSD slots and 2 x SD card slots, 1 x 6G-SDI input, 2 x 6G-SDI outputs, 1 x HDMI input, 1 HDMI output and 1 x SDI loop output, 1 x USB Type-C out. Uncompressed & H.264 10-bit 4:2:2 video; compressed in ProRes / DNxHD.
Key specifications: weight 4.65 lb / 2.1 kg; dimensions 19 x 9.3 x 1.74" / 48.3 x 23.6 x 4.4 cm; video input 1 x BNC 6G-SDI 1 x HDMI 2.0; audio output connector 1 x 1/4" Headphone Jack; network 1 x RJ45 1 Gb/s.
An external recorder captures higher-quality codecs than many cameras record internally. Manufacturer model number HYPERD/ST/DFHP.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Video Input | 1 x BNC 6G-SDI 1 x HDMI 2.0 |
|---|---|
| Video Output | 1 x BNC SDI Loop-Through 2 x BNC 6G-SDI 1 x SDI Monitor Output 1 x HDMI 2.0 |
| Embedded Audio | Input: 16 x Channels SDI 16 x Channels HDMI Output: 8 x Channels SDI 8 x Channels HDMI |
| Audio Output Connector | 1 x 1/4" Headphone Jack |
| Network | 1 x RJ45 1 Gb/s |
| SSD Interface | 2 x 2.5" SATA 3Gb/s |
| Reference Input | 1 x BNC |
| Reference Output | 1 x BNC |
| Timecode Input | 1 x BNC |
| Timecode Output | 1 x BNC |
| Device Control | 1 x RS-422 Input 1 x RS-422 Output |
| Display Size | 2.2" LCD |
| Speaker | Mono |
| Format Support | DCI/UHD 4K 2160p: 30/29.97/25/24/23.98 2K 1440p: 30/29.97/25/24/23.98 1080p: 60/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 NTSC/PAL 525i 59.94 625i 50 480p60 and 576p50 via HDMI only |
| Supported Operating Systems | macOS 10.15 Catalina macOS 11.1 Big Sur or Later Windows 10, 64-Bit |
| Other Outputs | 1 x USB Type-C for External Recording or Webcam Use |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2084, and SMPTE 2108-1 |
| SDI Metadata Support | HD RP188 and closed captioning CEA‑708 HDR Metadata supported on SDI |
| Sampling | Video: 4:2:2 YUV Audio: 24-Bit, 48 kHz |
| Colour Precision | 10-Bit |
| Colour Space | REC 601, REC 709, REC 2020 3D LUTS can be Applied to SDI Monitor Out |
| Multiple Rate Support | Auto-Detection of SD, HD and 6G-SDI |
| HDR Support | Hybrid Log Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084 |
| Codecs Supported | ProRes HQ QuickTime ProRes 422 QuickTime ProRes LT QuickTime ProRes Proxy QuickTime for all Formats up to 2160p30 Playback only of: ProRes 4444 QuickTime up to 1080p60 with Auto Routing of Fill and Key over SDI A and B Outputs DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD Formats up to 60 fps DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p Formats up to 30 fps H.264 SDI 4:2:2 10-Bit, H.264 High 4:2:0 8-Bit, H.264 Medium 4:2:0 8-Bit, H.264 Low 4:2:0 8-Bit for all Progressive Formats up to 1080p60 |
| Media Slots | 2 x 2.5" SSD 2 x SD Card |
| Rack Size | 1 RU |
| Power Input | 1 x 110 to 240 VAC, 50/60 Hz Power Input 1 x 12 VDC, 4-Pin XLR Input |
| Power Consumption | 100 W Maximum |
| Operating Temperature | 32to 104°F/ 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Relative Humidity | 0 to 90% Non-Condensing |
| Dimensions | 19 x 9.3 x 1.74" / 48.3 x 23.6 x 4.4 cm |
| Weight | 4.65 lb / 2.1 kg |
In the box
- Blackmagic Design HyperDeck Studio HD Pro
