Description
The Blackmagic Design DeckLink SDI 4K Capture & Playback Card is an internal interface.
Highlights include SD/HD/3G/6G-SDI Input/Output, PCIe Interface, UHD / DCI 4K 4:2:2 by Single-Link 6G-SDI, 1080p 4:4:4 by Single-Link 3G-SDI and 10-Bit Processing.
Key specifications: weight 4.5 oz / 128 g; dimensions 3.75" / 9.53 cm; host connection PCIe x1 (PCIe 1.0); video input connectors 1 x BNC (6G-SDI); operating temperature 41 to 104°F / 5 to 40°C.
In the box: Blackmagic Design DeckLink SDI 4K capture & playback card and SD Card with Support Software/Drivers.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Host Connection | PCIe x1 (PCIe 1.0) |
|---|---|
| Input | |
| Video Input Connectors | 1 x BNC (6G-SDI) |
| Input Video Format | SDI (10-Bit 4:4:4/4:2:2) PAL: 50 fps NTSC: 59.94 fps 720p: 50/59.94/60 fps 1080p: 23.98/24/25/30/50/59.94/60 fps 1080PsF: 23.98/24/25/29.97/30 fps 1080i: 50/59.94/60 fps UHD 4K: 23.98/24/25/29.97/30 fps DCI 4K: 23.98/24/25 fps DCI 2K: 23.98/24/25 fps |
| Output | |
| Video Output Connectors | 1 x BNC (6G-SDI) |
| Output Video Format | SDI (10-Bit 4:4:4/4:2:2) PAL (768 x 576): 50 fps NTSC: 59.94 fps 720p: 50/59.94/60 fps 1080p: 23.98/24/25/30/50/59.94/60 fps 1080PsF: 23.98/24/25/29.97/30 fps 1080i: 50/59.94/60 fps UHD 4K: 23.98/24/25/29.97/30 fps DCI 4K: 23.98/24/25 fps DCI 2K: 23.98/24/25 fps |
| Standards | |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/425M/ST-2081 ITU -R BT.601/BT.656 |
| HDCP Support | None |
| Environmental | |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| General | |
| Certifications | C-Tick, COE, FCC, as per Manufacturer |
| Dimensions | 3.75" / 9.53 cm |
| Weight | 4.5 oz / 128 g |
In the box
- Blackmagic Design DeckLink SDI 4K Capture & Playback Card
- SD Card with Support Software/Drivers
