Description
The NUX B-7 PRO Wireless In-Ear Monitor System sits in our Wireless In-Ear Monitors range.
Highlights include delivers 24-bit/48kHz sound, latency as low as 7.3ms, operates up to 50 meters and customizable color LCD display.
Key specifications: frequency response 20Hz-20kHz; battery lifetime TX: Up to 6 hours/ RX: Up to 6 hours; operating frequency band 2400-2483.5MHz; transmit mode Frequency Hopping; RF output power 10mW E.l.R.P. max.
An external monitor gives a larger, brighter view with exposure and focus tools the camera screen lacks.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Operating Frequency Band | 2400-2483.5MHz |
|---|---|
| Transmit Mode | Frequency Hopping |
| RF Output Power | 10mW E.l.R.P. max |
| Audio Quality | 24bit/48kHz |
| Frequency Response | 20Hz-20kHz |
| Latency | 7.33ms(low latency setting)-10.85ms(default)-14.33ms(safe setting) |
| Unbalanced Input lmpedance | 10kΩ |
| Balanced Input lmpedance | 20kΩ |
| AUX Input Level | 2.1 Vrms(8.7dBu) max |
| Balanced Input Level | 9.8 Vrms(22dBu)max |
| Headphone output Impedance | Minimum 13Ω |
| Headphone Maximum output power per channel | 57mW (THD<0.1% RLOAD=16Ω,1kHz) |
| Channel separation | -105dB |
| THD+N | <0.01% typical |
| Dynamic Range | 110dB A-weighted |
| Output level Adjustment Range | Mute -86dB~+12dB |
| Auto-off | It automatically turns off after 10 minutes of no connection or if the connection is lost |
| Built-in Battery Capacity | Rechargeable Li-polymer (Transmitter 3.7V/3000mAh, receiver 3.7V/400mAh) |
| Battery Lifetime | TX: Up to 6 hours/ RX: Up to 6 hours |
| Power Requirements | DC 9V, 1A min, negative tip power supplies(Transmitter) |
| Operation Range | Up to 50m (165 feet) maximum |
| TX Dimesions | 140mm 97mm 53mm (L W H) |
| TX Weight | 525g |
| RX Dimensions | 47mm 71mm 22mm (L W H) |
| RX Weight | 51g |
In the box
- NUX B-7 PRO Wireless In-Ear Monitor System
