Description
The Neutrik NC3FXX-B Connector - Gold Contacts sits in our 3 Pin XLR range. Compatible with Cable outer diameter 3.5 - 8.0 mm; conductor size up to 2.5 mm² / 14 AWG.
Highlights include 3-pole female XLR cable connector, solder contacts, latch lock, black KTL shell coating and IEC 61076-2-103 compliant.
Key specifications: cable connector XLR 3-Pin Female; connection type XLR; gender female; number of contacts 3; contact plating 0.2 µm Au hard alloy over 2 µm Ni.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| Connection type | XLR |
|---|---|
| Gender | female |
| Number of contacts | 3 |
| Contact plating | 0.2 µm Au hard alloy over 2 µm Ni |
| Contact material | Bronze (CuSn8) |
| Cable O.D. | 3.5 - 8.0 mm |
| Wiresize max. | 2.5 mm² / 14 AWG |
| Rated current per contact | 16 A |
| Rated voltage | < 50 V |
| Contact resistance | ≤ 3 mΩ |
| Dielectric strength | 1.5 kVdc |
| Protection class | IP 40 |
Product details
| Cable Connector | XLR 3-Pin Female |
|---|---|
| Compatible With | Cable outer diameter 3.5 - 8.0 mm; conductor size up to 2.5 mm² / 14 AWG |
