Description
The Lenkeng HDMI & IR Extender Kit sits in our HDMI range.
Highlights include zero latency, support up to 4K@30Hz resolution, support bi-directional IR pass-back function(20~60KHz), support HDR10 and support EDID passthrough.
Key specifications: dimensions (L×W×H mm) 80.0 (L) x 75.0 (W) x 18.0 (H) mm |; HDMI compliance HDMI1.4 |; HDCP compliance HDCP1.4 |; transmission medium CAT6/CAT6A/CAT7 |; video bandwidth 10.2Gbps |.
Manufacturer model number LKV223P.
The price includes GST and shipping is free Australia-wide; the dispatch time is shown above the add-to-cart button.
Specifications
| HDMI compliance | HDMI1.4 | |
|---|---|
| HDCP compliance | HDCP1.4 | |
| Transmission medium | CAT6/CAT6A/CAT7 | |
| Transmission distance | 1080@60Hz Transmission ≤ 70 meters; 4K@30Hz Transmission ≤ 40m | |
| Video bandwidth | 10.2Gbps | |
| Video support | 800x600, 1024x768, 1280x720, 1280x960, 1366x768, 1440x900, 1680x1050, 1920x1080, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60Hz, 4K@24/25/30Hz | |
| Audio support | PCM/LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby TrueHD 5.1CH | |
| 1080P HDR10 (YUV4:4:4) | Support | |
| HDMI Loop-out | Support | |
| EDID through | Support | |
| Bi-directional IR passback | Support | |
| Input TMDS signal | 0.7~1.2Vp-p | |
| Input DDC signal | 5Vp-p | |
| Input | HDMI×1, DC2.1×1, 3.5mm jack ×1 (IR) | DC2.1×1, RJ45×1, 3.5mm jack ×1 (IR), 3.5mm L/R ×1 |
| Output | HDMI×1, RJ45 ×1, 3.5mm jack ×1 (IR) | HDMI×1, RJ45×1, 3.5mm jack ×1 (IR) |
| HDMI connector | Type A 19 Pins, Female | |
| Network cable standard | CAT5E/CAT6/CAT6A/CAT7 , follow IEEE-5688 standard | |
| Mechanical | Transmitter | Receiver |
| Housing | Aluminium alloy material+crystal panel | |
| Dimensions (L×W×H mm) | 80.0 (L) x 75.0 (W) x 18.0 (H) mm | |
| Net weight | 160g | 160g |
| Power supply | 5V/2A | |
| Power consumption | <4W | <4W |
| Operation tempertaure | -20°C~60°C | |
| Storage temperature | -30°C~70°C | |
| Relative humidity | 0%~90% (no condensation) | |
In the box
- Lenkeng HDMI & IR Extender Kit
