Description
The Insta360 X5 is a 360 degree camera for creators and videographers who want to capture a scene first and choose the framing later. It suits users who need dual lens recording, 360 degree reframing and flexible shooting modes in a compact camera for action, travel and event work.
It records in 8K 360 video and supports 72 MP stills in DNG or INSP formats. The camera uses dual 1/1.28-inch CMOS sensors, a 6 mm lens with f/2 aperture and a 170 degree angle of view per lens. It includes internal and external stitching, gesture control, dual and single lens modes, Bullet Time, time lapse and InstaFrame.
In use, it can be paired with a microSD card up to 1 TB, with U3 or V30 speed recommended. The fixed 2.5 inch touchscreen is used for framing and control, and audio is captured through the built-in stereo microphone. In the box are the Insta360 X5 camera, USB-C charging cable, protective pouch and lens cloth.
Specifications
| 360 Stitched Video Recording | |
|---|---|
| Stitching Resolution | 8K (Photo) 8K (Video) |
| Internal/External Stitching | Internal, External Stitching |
| 360 Stitched Video Format | 7680 x 4320 at 24, 25, 30 fps (INSV) 5760 x 2880 at 24, 25, 30 fps (INSV) 5760 x 2880 at 24, 25, 30, 50, 60 fps (INSV) 3840 x 1920 at 24, 25, 30, 50, 60, 100 fps (INSV) |
| Still Image Support | DNG / INSP 72 MP 18 MP |
| Number of Lenses | 2 |
| Camera per Lens | |
| Image Sensor | 1/1.28"-Type CMOS |
| Sensor Resolution | Effective: 72 Megapixel (11,904 x 5952) |
| Optics per Lens | |
| Focal Length | 6mm |
| Maximum Aperture | f/2 |
| Lens Elements | 2 |
| Angle of View | Ultra Wide: 170° (Per Lens) |
| Recording per Lens | |
| Video Format | 3840 x 2160p at 24/25/30/60 fps (200 Mb/s MP4 via H.264/AVC, H.265/HEVC) 2720 x 1536p at 24/25/30/50/60/100/120 fps (200 Mb/s MP4 via H.264/AVC, H.265/HEVC) 1920 x 1080p at 24/25/30/50/60/100/120 fps (200 Mb/s MP4 via H.264/AVC, H.265/HEVC) |
| Recording | |
| Media/Memory Card Slot | Single Slot: microSD/microSDHC (UHS-I) [1 TB Maximum / U3/V30 or Faster Recommended] |
| Built-In Mic | Yes |
| Channels | 2.0-Channel Stereo |
| Audio Format | AAC |
| Sampling Frequency | AAC: 48.0 kHz |
| Display | |
| Display Type | Fixed Touchscreen LCD |
| Display Size | 2.5" |
| Features | |
| Built-In Speaker | No |
| Environmental Resistance | Water-Resistant to 32.8' / 10 m (Unrated) |
| Wireless | Wi-Fi 5 (802.11ac) / Bluetooth 5.2 |
| Mobile App Compatible | Yes: Android & iOS App Name: Insta360 Functionality: Access Stored Files, Firmware Update, Remote Control, Setup, View Live Feed |
| IP Streaming | No |
| Tripod Mounting Thread | 1x 1/4"-20 Female (Bottom) |
| Input/Output Connectors | |
| Inputs | No |
| Outputs | 1x USB-C 3.0 |
| Headphone Jack | No |
| General | |
| Battery | Rechargeable Lithium-Ion Battery Pack, 2400 mAh Max Runtime: 3 Hours per Charge Battery Charge Time: 0.5 hours |
| Charging Method | USB |
| Power Adapter | No |
| Operating Temperature | -4 to 104°F / -20 to 40°C |
| Dimensions (W x H x D) | 4.9 x 1.8 x 1.5" / 124.5 x 46 x 38.2 mm |
| Weight | 7.1 oz / 200 g (Body Only) |
In the box
- Insta360 X5 360° 8K Camera
- USB-C Charging Cable
- Protective Pouch
- Lens Cloth
