Description
The DJI Osmo Action 4 Standard Combo is a compact action camera for outdoor filming, travel, sport and hands on content creation. It suits users who want a small camera with strong video features, simple mounting options and a body that is easy to carry. It records stills and video in a format that works well for fast moving scenes and everyday use.
It uses a 1/1.3-inch CMOS sensor, a 155° lens with f/2.8 aperture and focus from 0.4 m to infinity. Photo resolution reaches 3648 × 2736, with JPEG and RAW support. Video is saved as MP4 in H.264 or HEVC, with up to 130 Mbps bitrate. It also supports 10-bit and D-Log M colour, 4K at 120 fps, 360° HorizonSteady and digital zoom up to 4x for photos and 2x for video.
In use, it pairs with microSD cards up to 512 GB and suits users building a portable action setup. The camera measures 70.5 × 44.2 × 32.8 mm and weighs 145 g, so it stays compact on a rig or mount. The box includes the camera, extreme battery, horizontal-vertical protective frame, quick-release adapter mount, curved adhesive base, locking screw, Type-C to Type-C PD cable, lens hood, anti-slip pad and DJI logo sticker.
Specifications
| General | |
|---|---|
| Dimensions | 70.5×44.2×32.8 mm (L×W×H) |
| Weight | 145 g |
| Waterproof | 18 m without the Waterproof Case, 60 m with the Waterproof Case Before use, close the battery compartment cover and the USB-C port cover, and tighten the Glass Lens Cover. It is recommended to install the Waterproof Case for long-duration underwater shooting or in environments with high water impact pressure. Osmo Action 4 and its Waterproof Case have an IP68 waterproof rating. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids. |
| Number of Microphones | 3 |
| Touchscreens | Front Screen: 1.4-inch 323 ppi 320×320 Rear Screen: 2.25-inch 326 ppi 360×640 Front/Rear Screen Brightness: 750±50 cd/m²" |
| Supported SD Cards | microSD (up to 512 GB) |
| Recommended microSD Cards | Recommended models: SanDisk Extreme Pro 32GB V30 A2 UHS-I Speed Grade 3 Kingston Canvas Go!Plus 64GB UHS-I Speed Grade 3 Kingston Canvas Go!Plus 128GB UHS-I Speed Grade 3 Kingston Canvas React Plus 64GB UHS-II Speed Grade 3 Kingston Canvas React Plus 128GB UHS-II Speed Grade 3 Kingston Canvas React Plus 256GB UHS-II Speed Grade 3 Lexar Pro 512GB SDXC UHS-I V30 R160/W120 (1066x) Lexar Pro 256GB SDXC UHS-I V30 R160/W120 (1066x) |
| Camera | |
| Sensor | 1/1.3-inch CMOS |
| Lens | FOV: 155° Aperture: f/2.8 Focus Range: 0.4 m to ∞ |
| ISO Range | Photo: 100-12800 Video: 100-12800 |
| Electronic Shutter Speed | Photo: 1/8000-30 s Video: 1/8000 s to the limit of frames per second |
| Max Photo Resolution. | 3648 × 2736 |
| Zoom | Digital Zoom Photo: 4× Video: Max 2× Slow Motion/Timelapse: Not available |
| Still Photography Modes | Single: Approx. 10 MP Countdown: Off/0.5/1/2/3/5/10 s |
| Standard Recording | 4K (4:3): 3840×2880@24/25/30/48/50/60fps 4K (16:9): 3840×2160@100/120fps 4K (16:9): 3840×2160@24/25/30/48/50/60fps 2.7K (4:3): 2688×2016@24/25/30/48/50/60fps 2.7K (16:9): 2688×1512@100/120fps 2.7K (16:9): 2688×1512@24/25/30/48/50/60fps 1080p (16:9): 1920×1080@100/120/200/240fps 1080p (16:9): 1920×1080@24/25/30/48/50/60fps |
| Slow Motion | 4K: 4× (120fps) 2.7K: 4× (120fps) 1080p: 8× (240fps), 4× (120fps) |
| Hyperlapse | 4K/2.7K/1080p: Auto/×2/×5/×10/×15/×30 |
| Timelapse | 4K/2.7K/1080p@30fps Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s Duration: 5/10/20/30 mins, 1/2/3/5 hours, ∞ |
| Stabilisation | EIS: RockSteady 3.0 RockSteady 3.0+ HorizonBalancing HorizonSteady EIS is not supported in Slow Motion and Timelapse modes. HorizonSteady is only available when the video resolution is 1080p (16:9) or 2.7K (16:9) with a frame rate of 60fps or below. HorizonBalancing is only available when the video resolution is 1080p (16:9), 2.7K (16:9), or 4K (16:9) with a frame rate of 60 fps or below. |
| Max Video Bitrate | 130 Mbps |
| Supported File System | exFAT |
| Photo Format | JPEG/RAW |
| Video Format | MP4 (H.264/HEVC) |
| Built-in Storage Capacity | The camera does not have built-in storage, but storage capacity can be expanded by inserting a microSD card. |
| Audio Output | 48 kHz 16-bit; AAC |
| Battery | |
| Operating Time | 160 minutes Tested at room temperature (25°C/77°F) and 1080p/24fps (16:9), with RockSteady on, Wi-Fi off, and screen off. This data is for reference only. |
| Connection | |
| Wi-Fi Operating Frequency | 2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz |
| Wi-Fi Protocol | 802.11 a/b/g/n/ac |
| Wi-Fi Transmitter Power (EIRP) | 2.4 GHz: < 15 dBm (FCC/CE/SRRC/MIC) 5.1 GHz: < 16 dBm (FCC/CE/SRRC/MIC) 5.8 GHz: < 14 dBm (FCC/CE/SRRC)" |
| Bluetooth Operating Frequency | 2.400-2.4835 GHz |
| Bluetooth Transmit Power (EIRP) | <3 dBm |
| Bluetooth Protocol | BLE 5.0 |
Product details
| Series/Compatibility | Osmo |
|---|
In the box
- Osmo Action 4
- Osmo Action Extreme Battery
- Osmo Action Horizontal-Vertical Protective Frame
- Osmo Action Quick-Release Adapter Mount
- Osmo Action Curved Adhesive Base
- Osmo Locking Screw
- Type-C to Type-C PD Cable
- Osmo Action Lens Hood
- Osmo Action Anti-Slip Pad
- DJI Logo Sticker
- Quick Start Guide
- Disclaimer
- Warranty Card
